High Temperature Weldable Strain Gauge AWMD-5, AWMD-8 (for dynamic measurement only : -196 to +800) Full bridge

AWMD-5, AWMD-8 (for dynamic measurement only : -196 to +800℃) Full bridgeCE_logo

The AWMD is applicable up to 800°C and is dedicated to dynamic measurement. A high pass filter is a standard accessory. Using the high pass filter, unnecessary direct current component and low frequency component (thermal output, drift, etc.) are cancelled. A DC exciting dynamic strainmeter such as DC-96A/DC-97A, smart strain recorder such as DC-204R, or multi-recorder TMR-200 series should be used for the measurement.

Main object material Metal
Operational temperature -196 to +800℃
Temperature compensation range -
Bonding adhesive Spot welding (TML spot welder W-50R is required)
Backing Inconel 600
Element Special alloy
Strain limit 1% (10000 x 10-6 strain)
Fatigue life at room temperature 1 to 106 (±1000 x 10-6 strain)

  • Specifications
    awmd-5-8
    Type Gauge
    length
    (mm)    		 Gauge base Test specimen Resistance in (Ω)
    Dimensions (mm) Material
    AWMD-5-AKM-2(6F)-1.6Hz 5 L10 x W3 x T0.7 Inconel 600 Inconel 600 equivalent 60
    AWMD-8-A-2-1.6Hz 8 L16 x  W5 x T0.7 120

    Each package contains one strain gauge.
    Other cable length available on request
    (Made to order by every 1 m for MI cable and by every 0.5 m for vinyl cable)

Recommended lead wires for leadwire-integrated strain gauges

Recommended lead wires for leadwire-integrated strain gauges

Where we had previously indicated type for 2-wire system leads with -♦L and 3-wire systems with -♦LT for standard vinyl leadwire-integrated strain gauges regardless of type of lead wire, we changed to a symbology for indicating lead wire types in April of 2017 to accommodate products such as those with lead-free solder (option –F) as part of our efforts to make environmentally friendly CE-compliant products.
Although there is no information given in the catalog on F/P/PF series leadwire-integrated strain gauges, this is handled as it has been. Combinations are available of all strain gauges and lead wires for strain gauges. Combinations are also available of lead wires for temperature-integrated strain gauges and all foil strain gauges.

Chart of strain gauge and dedicated lead wire combinations

  • Lead wires recommended for F series

    For general strain measurement

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    General measurement
    (no temperature change)    		 2-wire parallel vinyl wire LJB －20 to ＋80 FLA-5-11-3LJB
    2-wire parallel vinyl wire LJC FLA-5-11-3LJC
    General measurement 3-wire parallel vinyl wire LJBT －20 to ＋80 FLA-5-11-3LJBT
    3-wire parallel vinyl wire LJCT FLA-5-11-3LJCT
    Medium/high temperature 3-wire parallel special vinyl wire LXT －20 to ＋150 FLA-5-11-3LXT
    Temperature-integrated 3-wire parallel vinyl wire TLJBT －20 to ＋80 FLA-5T-11-3TLJBT
    1-gauge 4-wire method Polypropylene 4-wire parallel wire
    (with modular)    		 LQM －20 to ＋100 FLA-5-11-3LQM

    Residual stress measurement / shear strain / stress concentration measurement

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    General measurement
    (no temperature change)    		 2-wire parallel vinyl wire LJB/LJB-F －20 to ＋80 FLA-5-11-3LJB
    General measurement 3-wire parallel vinyl wire LJBT/LJBT-F －20 to ＋80 FLA-5-11-3LJBT
    Medium/high temperature 3-wire parallel special vinyl wire LXT/LXT-F －20 to ＋150 FLA-5-11-3LXT
    1-gauge 4-wire method Polypropylene 4-wire parallel wire
    (with modular)    		 LQM/LQM-F －20 to ＋100 FLA-5-11-3LQM

    GOBLET series (CE mark) for general strain measurement

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    General measurement
    (no temperature change)    		 2-wire parallel vinyl wire LJB-F －20 to ＋80 FLAB-5-11-3LJB-F
    2-wire parallel vinyl wire LJC-F FLAB-5-11-3LJC-F
    General measurement 3-wire parallel vinyl wire LJBT-F －20 to ＋80 FLAB-5-11-3LJBT-F
    3-wire parallel vinyl wire LJCT-F FLAB-5-11-3LJCT-F
    Medium/high temperature 3-wire parallel special vinyl wire LXT-F －20 to ＋150 FLAB-5-11-3LXT-F
    Temperature-integrated 3-strand twisted FEP single-core wire 6FB♦TLT-F －196 to ＋150 FLAB-5T-11-6FB3TLT-F
    1-gauge 4-wire method Polypropylene 4-wire parallel wire
    (with modular)    		 LQM-F －20 to ＋100 FLAB-5-11-3LQM-F

    * Only lead wires using lead-free solder are available for GOBLET series strain gauges with the CE marking.

  • Lead wires recommended for QF series strain gauges for high temperature use (made-to-order)

    Lead wires recommended for QF series strain gauges

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    General measurement
    (no temperature change)    		 2-wire parallel vinyl wire LJC-F －20 to ＋80 QFLAB-1-11-3LJC-F
    General measurement 3-wire parallel vinyl wire LJCT-F －20 to ＋80 QFLAB-1-11-3LJCT-F
    Waterproof 3-strand twisted cross-linked vinyl wire LJRTA －20 to ＋100 QFLA-1-11-3LJRTA
    Temperature-integrated 3-strand twisted FEP single-core wire 6FB♦TLT-F －20 to ＋200 QFLAB-1-11-6FB3TLT-F
    High temperature 3-strand twisted FEP wire 6FA♦LT-F －20 to ＋200 QFLAB-1-11-6FA3LT-F
    3-strand twisted FEP wire
    (Surface treatment(tetraetching) is not required)    		 6FAS♦LT-F QFLAB-1-11-6FA3LT-F
    3-strand twisted FEP single-core wire 6FB♦LT-F QFLAB-1-11-6FB3LT-F
    3-strand twisted FEP wire
    (Surface treatment(tetraetching) is not required)    		 6FCS♦LT-F QFLAB-1-11-6FCS3LT-F

    * “♦” indicates lead wire length

  • Lead wires recommended for ZF series High temperature use strain gauge (made-to-order)

    Lead wires recommended for ZF series strain gauges

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    General measurement
    (no temperature change)    		 2-wire parallel vinyl wire LJC-F －20 to ＋80 ZFLA-3-350-11-3LJC-F
    General measurement 3-wire parallel vinyl wire LJCT-F －20 to ＋80 ZFLA-3-350-11-3LJCT-F
    Waterproof 3-strand twisted cross-linked vinyl wire LJRTA －20 to ＋100 ZFLA-3-350-11-3LJRTA
    High temperature 3-strand twisted FEP wire 6FA♦LT-F －269 to ＋200 ZFLA-3-350-11-6FA3LT-F
    3-strand twisted FEP wire
    (Surface treatment(tetraetching) is not required)    		 6FAS♦LT-F ZFLA-3-350-11-6FAS3LT-F
    3-strand twisted FEP single-core wire 6FB♦LT-F ZFLA-3-350-11-6FB3LT-F
    3-strand twisted FEP wire
    (Surface treatment(tetraetching) is not required)    		 6FCS♦LT-F ZFLA-3-350-11-6FCS3LT-F
    3-strand twisted PTFE wire 4FA♦LT-F －269 to ＋260
    (if only short time,
    up to 300°C)    		 ZFLA-3-350-11-4FA3LT-F
    3-strand twisted PTFE single-core wire 4FB♦LT-F ZFLA-3-350-11-4FB3LT-F

    * “♦” indicates lead wire length

  • Lead wires recommended for CEF series High and low temperature strain gauge (made-to-order)

    Lead wires recommended for CEF series strain gauges

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    High and low temperature 3-strand twisted FEP wire 6FA♦LT-F －269 to ＋200 CEFLA-1-11-6FA3LT-F
    3-strand twisted FEP wire
    (Surface treatment(tetraetching) is not required)    		 6FAS♦LT-F CEFLA-1-11-6FAS3LT-F
    3-strand twisted FEP single-core wire 6FB♦LT-F CEFLA-1-11-6FB3LT-F
    3-strand twisted FEP wire
    (Surface treatment(tetraetching) is not required)    		 6FCS♦LT-F CEFLA-1-11-6FCS3LT-F
    3-strand twisted PTFE wire 4FA♦LT-F －269 to ＋260 CEFLA-1-11-4FA3LT-F
    3-strand twisted PTFE single-core wire 4FB♦LT-F CEFLA-1-11-4FB3LT-F

    * “♦” indicates lead wire length

  • Lead wires recommended for CF series Cryogenic temperature use strain gauge (made-to-order)

    Lead wires recommended for CF series strain gauges

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    Cryogenic temperature-F 3-strand twisted FEP wire 6FA♦LT-F －269 to ＋200 CFLA-1-350-11-6FA3LT-F
    3-strand twisted FEP wire
    (Surface treatment(tetraetching) is not required)    		 6FAS♦LT-F CFLA-1-350-11-6FAS3LT-F
    3-strand twisted FEP single-core wire 6FB♦LT-F CFLA-1-350-11-6FB3LT-F
    3-strand twisted FEP wire
    (Surface treatment(tetraetching) is not required)    		 6FCS♦LT-F CFLA-1-350-11-6FCS3LT-F
    3-strand twisted PTFE wire 4FA♦LT-F －269 to ＋260 CFLA-1-350-11-4FA3LT-F
    3-strand twisted PTFE single-core wire 4FB♦LT-F CFLA-1-350-11-4FB3LT-F

    * “♦” indicates lead wire length

  • Lead wires recommended for P series Polyester wire strain gauge

    Lead wires recommended for P series strain gauges (CE mark)

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    General measurement
    (no temperature change)    		 2-wire parallel vinyl wire LJB-F －20 to ＋80 PL-60-11-3LJB-F
    2-wire parallel vinyl wire LJC-F PL-60-11-3LJC-F
    General measurement 3-wire parallel vinyl wire LJBT-F －20 to ＋80 PL-60-11-3LJBT-F
    3-wire parallel vinyl wire LJCT-F PL-60-11-3LJCT-F
    1-gauge 4-wire method Polypropylene 4-wire parallel wire
    (with modular)    		 LQM-F －20 to ＋100 PL-60-11-3LQM-F

    * “♦” indicates lead wire length
    * 2-element and 3-element gauges cannot be additionally outfitted with a lead wire
    * Only lead wires using lead-free solder are available for  strain gauges with the CE marking

  • Lead wires recommended for PF series Polyester foil strain gauge

    Lead wires recommended for PF series strain gauges (CE mark)

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    General measurement
    (no temperature change)    		 2-wire parallel vinyl wire LJB-F －20 to ＋80 PFL-10-11-3LJB-F
    2-wire parallel vinyl wire LJC-F PFL-10-11-3LJC-F
    General measurement 3-wire parallel vinyl wire LJBT-F －20 to ＋80 PFL-10-11-3LJBT-F
    3-wire parallel vinyl wire LJCT-F PFL-10-11-3LJCT-F
    1-gauge 4-wire method Polypropylene 4-wire parallel wire
    (with modular)    		 LQM-F －20 to ＋100 PFL-10-11-3LQM-F

    * 2-element and 3-element gauges cannot be additionally outfitted with a lead wire
    * Only lead wires using lead-free solder are available for  strain gauges with the CE marking

  • Lead wires recommended for UBF series Composite strain gauge (made-to-order)

    Lead wires recommended for UBF series strain gauges

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    General measurement
    (no temperature change)    		 2-wire parallel vinyl wire LJB-F －20 to ＋80 UBFLA-1-3LJB-F
    2-strand twisted vinyl wire LH UBFLA-1-3LH
    General measurement 3-wire parallel vinyl wire LJBT-F －20 to ＋80 UBFLA-1-3LJBT-F
    3-strand twisted vinyl wire (3-wire system) LHT UBFLA-1-3LHT
    Medium/high temperature 3-wire parallel special vinyl wire LXT-F －20 to ＋150 UBFLA-1-3LXT-F
    3-strand twisted FEP single-core wire 6FB♦LT-F －269 to ＋200 UBFLA-1-6FB3LT-F

    * “♦” indicates lead wire length

  • Lead wires recommended for BF series Composite strain gauge (made-to-order)

    Lead wires recommended for BF series strain gauges

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    General measurement
    (no temperature change)    		 2-wire parallel vinyl wire LJB-F －20 to ＋80 BFLAB-2-3-3LJB-F
    2-wire parallel vinyl wire LJC-F BFLAB-2-3-3LJC-F
    General measurement 3-wire parallel vinyl wire LJBT-F －20 to ＋80 BFLAB-2-3-3LJBT-F
    3-wire parallel vinyl wire LJCT-F BFLAB-2-3-3LJCT-F
    Medium/high temperature 3-wire parallel special vinyl wire LXT-F －20 to ＋150 BFLAB-2-3-3LXT-F
    3-strand twisted FEP single-core wire 6FB♦LT-F －269 to ＋200 BFLAB-2-3-6FB3LT-F
    Temperature-integrated 3-wire parallel vinyl wire TLJBT-F －20 to ＋80 BFLA-2T-3-3TLJBT-F
    3-strand twisted FEP single-core wire 6FB♦TLT-F －269 to ＋200 BFLA-2T-3-6FB3TLT-F

    * “♦” indicates lead wire length

  • Lead wires recommended for GF series Low elastic strain gauge (made-to-order)

    Lead wires recommended for GF series strain gauges

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    General measurement
    (no temperature change)    		 2-wire parallel vinyl wire LJC-F －20 to ＋80 GFLAB-3-50-3LJC-F
    General measurement 3-wire parallel vinyl wire LJCT-F －20 to ＋80 GFLAB-3-50-3LJCT-F

  • Lead wires recommended for LF series Strain gauges for Wood and Gypsum (made-to-order)

    Lead wires recommended for LF series strain gauges

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    General measurement
    (no temperature change)    		 2-wire parallel vinyl wire LJC-F －20 to ＋80 LFLAB-10-11-3LJC-F
    General measurement 3-wire parallel vinyl wire LJCT-F －20 to ＋80 LFLAB-10-11-3LJCT-F

  • Lead wires recommended for PFLW/PLW series strain gauges (made-to-order)

    Lead wires recommended for PFLW/PLW series strain gauges

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    General measurement
    (no temperature change)    		 2-wire parallel vinyl wire LJC/LJC-F －20 to ＋80 PFLW-30-11-3LJC
    General measurement 3-wire parallel vinyl wire LJCT/LJCT-F －20 to ＋80 PFLW-30-11-3LJCT
    Medium/high temperature 3-wire parallel special vinyl wire LXT/LXT-F －20 to ＋150 PFLW-30-11-3LXT
    1-gauge 4-wire method Polypropylene 4-wire parallel wire
    (with modular)    		 LQM/LQM-F －20 to ＋100 PFLW-30-11-3LQM

  • Lead wires recommended for MF series Magnetic field strain gauge (made-to-order)

    Lead wires recommended for MF series strain gauges

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    Single-element 2-strand twisted vinyl wire LJAY －20 to ＋80 MFLA-5-350-1LJAY
    ø3.2-mm 2-conductor shielded vinyl wire LS MFLA-5-350-1LS
    Two-element/three-element 2-strand twisted vinyl wire LJAY －20 to ＋80 MFCAL-2-1LJAY
    ø3.2-mm 2-conductor shielded vinyl wire LS MFCAL-2-1LJAY
    ø1.5-mm 3-conductor shielded FEP wire (3-wire system) 6FD♦LTS －269 to ＋200 MFCAL-2-6FD1LTS

    * “♦” indicates lead wire length

  • Lead wires recommended for YF/YEF/YHF series Post-yield Strain Gauge (made-to-order)

    Lead wires recommended for YF/YEF/YHF series strain gauges

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    General measurement
    (no temperature change)    		 2-wire parallel vinyl wire LJC/LJC-F －20 to ＋80 YFLA-2-3LJC-F
    General measurement 3-wire parallel vinyl wire LJCT/LJCT-F －20 to ＋80 YFLA-2-3LJCT-F

  • Lead wires recommended for DSF series High Endurance Strain Gauge (made-to-order)

    Lead wires recommended for DSF series strain gauges

    Purpose Lead wires Lead wire symbol Operational temperature range
    (℃)    		 Gauge type exampled
    General measurement
    (no temperature change)    		 2-wire parallel vinyl wire LJC/LJC-F －20 to ＋80 DSFLA-2-350-3LJC
    General measurement 3-wire parallel vinyl wire LJCT/LJCT-F －20 to ＋80 DSFLA-2-350-3LJCT
    Medium/high temperature 3-wire parallel special vinyl wire LXT/LXT-F －20 to ＋150 DSFLA-2-350-3LXT
    3-strand twisted FEP single-core wire 6FB♦LT －269 to ＋200 DSFLA-2-350-6FB3LT

    * “♦” indicates lead wire length

Standard leadwire-integrated strain gauges

These series are standard leadwire-integrated strain gauges with 2-wire parallel vinyl wire and 3-wire parallel vinyl wire:  F series strain gauges for general use, P series polyester strain gauges, PF series polyester foil strain gauges.

General use strain gauge F series

General use strain gauge F series GOBLET

P series Polyester wire strain gauge

PF series Polyester foil strain gauge

Strain gauge with a connector　With strain gauge connector (standard length: 1m)

With strain gauge connector (standard length: 1m)

1 m lead with a strain gauge attached vinyl lead wire terminal connector. F, PF, P gauge connector will connect with the processing of the series lead. You can use the connector with strain gauge and the specimen if there is more than one such body the same gauge connection in the vicinity of the specimen to be extended, No need for wiring to reduce the disposal of the lead can.
* Connector block is sold separately.

With strain gauge connector (standard length: 1m)

  • Specifications

    Strain gauge with connector (2-wire)

    Type (1m with) ♦-1LCJC
    Of core / diameter
    (cross section)    		 10/0.12 (0.11 mm2)

    (♦: Type Gauge)



    Connectors with strain gauge (3-wire)

    Type (1m with) ♦-1LCJCT
    Of core / diameter
    (cross section)    		 10/0.12 (0.11 mm2)

    (♦: Type Gauge)

Temperature-integrated strain gauges (with thermocouple)

Temperature-integrated strain gauges (with thermocouple)

These are temperature-integrated strain gauges having our unique thermocouple added. F series and almost all other foil strain gauges can be fitted with this capability. The temperature contact is a tab on the strain gauge, and displays the same temperature as the strain gauge. This can be measured with any of our data loggers.
* Data loggers applicable to the measurement of these gauges are TDS-540/-530/-303/-300/-630/-602/ -601A/-601/-102/-101R and TC-32K/-31K. Measurement using a dynamic strainmeter is not possible.

fla2t3ltjbt

Slip-ring type Wheel Torque Measurement LTW-NA

Slip-ring type Wheel Torque Measurement LTW-NA　2.5kN・m

This is a torque transducer for measuring driving torque and braking torque while an automobile is traveling. Torque can be measured with analog output by connecting the slip-ring and dynamic strainmeter that come standard. The slip-ring has a built-in encoder, allowing an F/V converter to be connected for counting output pulse and thereby measure rotational velocity. Preparing a special rim and hub adapter also allows the torque transducer to be installed to any passenger automobile.


IP code  IP 54-equivalent

LTW-NA
Features
  • Lightweight
  • Waterproof structure allows measurement in rain
  • Special rim and adapter for each car model available, allowing measurement with the same offset as under standard conditions

  • Specifications
    Type LTW-2.5KNA
    Input/output system Slip-ring and encoder built in
    Capacity (gravitating system reference value) 2.5 kN・m (255 kgf・m)
    Rated output 1 mV/V (2000 × 10-6 strain) ±10%
    Nonlinearity 0.3% RO
    Hysteresis 0.3% RO
    Temperature effect on zero 0.01% RO/℃
    Temperature effect on span 0.01%/℃
    Compensated temperature range −20 to +80℃ (no freezing)
    Allowable temperature range −30 to +100℃ (no freezing)
    Allowable overload 150%
    Allowable bending moment 3.5 kN・m
    Allowable wheel load 20 kN
    Allowable exciting voltage 20 V
    Input/output resistance 700 Ω ±5%
    Effect of wheel load 0.5% RO or less for 5 kN wheel load
    Effect of side load 0.5% RO or less for 3 kN side load (300-mm tire radius)
    Applicable wheel size 12-in. or larger all types
    Applicable hub size 100 4-hole, 100 5-hole, 114.3 4-hole, 114.3 5-hole, etc. all types
    Weight Approx. 15 kg (15 × 6J wheel mounted)
    Supplied cable CT6-8P5/SWP-NP+SNP (ø6mm 8-conductor shielded polyurethane cable 5 m)

    Other than the above capacity, we can also make 5 kN・m, etc.

Dynamic Strainmeters Optional Accessory Thermocouple adaptor TA-01KT

Thermocouple adaptor TA-01KT

This adaptor is intended for temperature measurement by T or K type thermocouple using a DC exciting strainmeter. No external power source is required because the adaptor uses bridge excitation supplied from the strainmeter. It is small-sized and can be directly connected to the connector of a strainmeter, thus saving space for installation.

Thermocouple adaptor TA-01KT
Features
  • Small and light weight
  • External power source is not required
  • Built-in reference junction compensation
  • Isolation between input and output
  • Digital linearization offers excellent linearity
  • Burnout detection function provided
  • Calibration output for confirmation of strainmeter setting

  • Specifications
    Type TA-01KT
    Number of measurment point 1
    Applicable thermocouple K, T
    Measuring range K : -50 to +1000 ℃
    T : -50 to +300 ℃
    Response time 20 msec or less (0 to 90 %)
    Measuring apparatus that applies DC exciting dynamic strainmeter
    DC-004P
    DH-14A
    DC-204R/-204Ra
    DC-96A/-97A
    TMR-300/-200series
    Dimensions 22(W) x 41(H) x 70(D) mm (excluding projecting parts)
    Weight Approx. 100 g
    Power supply DC 1.95-5.3 V (constant voltage)



Low Elastic Strain Gauge Wood, Gypsum Use LF series Strain gauges for Wood and Gypsum

LF series Strain gauges for Wood and Gypsum

LF series strain gauges for wood and gypsum are foil gauges utilizing special plastic for the backing. The grid pattern is suited for measurement on materials having a low elastic modulus and reduces the stiffening effect of the strain gauge on the specimen. Gauges are self-temperature-compensated for 11×10-6/℃ materials.
A new series of strain gauges bearing the CE mark, GOBLET, has been added. This CE-compliant series of products is compliant with RoHS directives. These gauges exceed the capabilities of conventional strain gauges with lead-free soldering as well as a unique tab design. CE-compliant extension lead wires are also available.

Applicable specimen Wood, Gypsum
Operational temperature LF GOBLET ：-30 to +80 ℃
LF：-20 to +80 ℃
Temperature compensation range +10 to +80 ℃
Applicable adhesive CN-E
Backing Special plastics
Element Cu-Ni
Strain limit 3% (30000 x 10-6 strain)
Fatigue life at room temperature 1 x 106 (±1500 x 10-6 strain)

  • LOW ELASTIC MATERIALS - WOOD, GYPSUM USE goblet_log_s CE_logo
    Gauge pattern Type Gauge
    length
    (mm)    		 Gauge
    width
    (mm)    		 Backing
    length
    (mm)    		 Backing
    width
    (mm)    		 Resistance
    (Ω)
    lflab_1011 LFLAB-10-11 10 3.1 18.5 5.3 120

    Each package contains 10 gauges.
    * Attachment of lead wiring can be performed (made-to-order).

  • LOW ELASTIC MATERIALS - WOOD, GYPSUM USE
    Gauge pattern Type Gauge
    length
    (mm)    		 Gauge
    width
    (mm)    		 Backing
    length
    (mm)    		 Backing
    width
    (mm)    		 Resistance
    (Ω)
    lfla_1011 LFLA-10-11 10 3.1 18.5 5.3 120

    Each package contains 10 gauges.
    * Attachment of lead wiring can be performed (made-to-order).

  • Lead wires recommended for LF series strain gauges (made-to-order)

    Lead wires recommended for LF series strain gauges

    Purpose Lead wires Lead wire symbol Operating temperature range
    (℃ )    		 Gauge type exampled
    General measurement
    (no temperature change)    		 2-wire parallel vinyl wire LJC/LJC-F －20 to +80 LFLA-10-11-3LJC
    General measurement 3-wire parallel vinyl wire LJCT/LJCT-F －20 to +80 LFLA-10-11-3LJCT

    * Only lead wires using lead-free solder are available for GOBLET series strain gauges with the CE marking.

More Information

Dynamic Strainmeters Optional Accessory Carrying Case / Mounting Rack

Carrying Case / Mounting Rack

The carrying case/mounting rack is used for housing DA/DC series dynamic strainmeters to configure a multi-channel measurement system. The case/rack has a power switch, calibration switch and balancing button for operating all channels at the same time.

  • Carrying Case

    携帯用ケース

    This case is used to configure DA series or DC series units in multi-channel. A power switch, calibration switch, and balancing button are provided that can be used with all channels at the same time.

    Type Number of channels Dimensions (mm)
    P-4B 4 208(W) x 148(H) x 308(D) (except projecting parts)
    P-6B 6 288(W) x 148(H) x 308(D) (except projecting parts)
    P-8B 8 368(W) x 148(H) x 308(D) (except projecting parts)
    P-10B 10 448(W) x 148(H) x 308(D) (except projecting parts)



  • Computer Control Carrying case for DA-17A/DA-37A

    DA-17A/DA-37A用パソコンコントロール対応　携帯用ケース

    This is a case for making a multi-channel system with DA-17A/DA-37A dynamic strainmeters. When the DA-17A or DA-37A units are installed in this case, settings such as low pass filter, balancing, calibration and acquisition of set values and monitor values are available from a computer through LAN interface. A power switch, calibration switch and balancing button are also provided. Carrying cases available for 4-, 6-, 8-, and 10-channel systems.

    Type Number of channels Dimensions (mm)
    P-4AL 4 208(W) x 148(H) x 308(D) (except projecting parts)
    P-6AL 6 288(W) x 148(H) x 308(D) (except projecting parts)
    P-8AL 8 368(W) x 148(H) x 308(D) (except projecting parts)
    P-10AL 10 448(W) x 148(H) x 308(D) (except projecting parts)



  • Mounting Rack

    ラック

    This is a JIS rack to configure a system with up to 10 units of DA or DC series dynamic strainmeters. A power switch, calibration switch, and balancing button are provided that can be used with all channels at the same time.

    Type Number of channels Dimensions (mm)
    R-10B 10 480(W) x 149(H) x 311(D) (except projecting parts)



  • Fixing Stand

    When a single unit of DA or DC series dynamic strainmeter is used, this stand is attached to the bottom surface of the single unit. It assists to keep the unit upright.

  • One-touch Terminal SB-OT1B

    ワンタッチ端子　SB-OT1B

    This is a terminal capable of connecting a lead wire by merely pressing down the knob and inserting the lead wire into the hole of the terminal. The lead wire is secured by the spring force of the knob. This terminal is mounted on the input terminal of switching box or bridge box (SB-120SB, SB-121A, SB-351A or SB-122A). One terminal is used for one lead wire, so it is supplied by every 5 terminals.
